SUN HYDRAULICS
FLJAXDN
$336.46 USD
- SUN HYDRAULICS
- Material:FLJAXDN
- Model:FLJA-XDN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FLJAXDN (FLJAXDN) is a specialized filter element designed for hydraulic systems, available in both Surface Type Last Chance and Depth Style configurations. These elements are engineered with a high collapse pressure, ensuring durability and reliability when integrated into hydraulic lines. The flow path is strictly Port 2 to Port 1 and should not be reversed, even if a reverse free flow check valve is installed. The Surface Type element features a 304 stainless steel mesh media, with all internal components also crafted from 304 stainless steel, providing a 40 micron nominal rating and 63 micron absolute. This design allows the capture of errant particles that may bypass the main system filter or arise from component failures. The Depth Type elements utilize pleated microglass media with clear zinc-coated components, available in nominal ranges of 3, 10, and 25 microns. These filters have a Beta ratio detailed in the Performance Curves tab. For optimal performance, installation directly above the subplate is recommended to protect the entire valve stack from contaminants. The FLJAXDN series has an impressive capacity of up to 80 gpm (320 L/min) and can withstand a maximum operating pressure of 5000 psi (350 bar). It fits into cavity T18A and requires an installation torque between 350 - 375 lbf ft (475 - 508 Nm). This product is ideal for maintaining system cleanliness by capturing unforeseen particles during regular operation or sudden component failures, thereby extending the life of hydraulic systems without being obtrusive during normal use.
The Sun Hydraulics FLJAXDN (FLJAXDN) is a specialized filter element designed for hydraulic systems, available in both Surface Type Last Chance and Depth Style configurations. These elements are engineered with a high collapse pressure, ensuring durability and reliability when integrated into hydraulic lines. The flow path is strictly Port 2 to Port 1 and should not be reversed, even if a reverse free flow check valve is installed. The Surface Type element features a 304 stainless steel mesh media, with all internal components also crafted from 304 stainless steel, providing a 40 micron nominal rating and 63 micron absolute. This design allows the capture of errant particles that may bypass the main system filter or arise from component failures. The Depth Type elements utilize pleated microglass media with clear zinc-coated components, available in nominal ranges of 3, 10, and 25 microns. These filters have a Beta ratio detailed in the Performance Curves tab. For optimal performance, installation directly above the subplate is recommended to protect the entire valve stack from contaminants. The FLJAXDN series has an impressive capacity of up to 80 gpm (320 L/min) and can withstand a maximum operating pressure of 5000 psi (350 bar). It fits into cavity T18A and requires an installation torque between 350 - 375 lbf ft (475 - 508 Nm). This product is ideal for maintaining system cleanliness by capturing unforeseen particles during regular operation or sudden component failures, thereby extending the life of hydraulic systems without being obtrusive during normal use.
Sun filter elements are available as Surface Type (Last Chance) and Depth Style elements. The flow path is Port 2 to Port 1 and should not be used in reverse, even with a reverse free flow check valve installed. The elements have a high collapse pressure and are intended to be used in line with the system. Filter life will depend on initial system cleanliness and the amount of dirt ingression to the system when operating.
- Differential crush pressure is 3000 psid (210 bar).
- The flow path is Port 2 to Port 1 only.
- Installation directly above the subplate will protect the entire valve stack from particles.
- Surface type element features a 304 stainless steel mesh media. All internal components are 304 stainless steel.
- Surface Type elements have a 40 micron nominal rating (63 micron absolute).
- Surface Type elements are designed to capture errant particles that may not be trapped in the main system filter or particles resulting from a component failure.
- With a correctly assembled system, Surface Type elements will be unnoticed during regular operation, but will provide protection from sudden component failure.
- Surface Type (Last Chance) elements have a single layer stainless steel mesh supported by perforated sheet tube.
- Depth Type elements feature a pleated microglass media with clear zinc coated components.
- Depth type elements are available in 3 µm, 10 µm, and 25 µm nominal ranges.
- 3, 10, and 25 micron elements have a Beta ratio as shown in the Performance Curves tab.
| Cavity | T-18A |
| Series | 4 |
| Capacity | 80 gpm320 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft475 - 508 Nm |
| Seal kit - Cartridge | Viton: 990-018-006 |
