SUN HYDRAULICS
FLJAXDV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FLJAXDV (Material Number: FLJAXDV) is a specialized filter element designed for hydraulic systems, available in both Surface Type Last Chance and Depth Style configurations. It features a unidirectional flow path from Port 2 to Port 1 and should not be reversed, even with a reverse free flow check valve. This filter boasts a high collapse pressure, making it suitable for inline system use to protect the entire valve stack when installed directly above the subplate. The Surface Type element utilizes a 304 stainless steel mesh media and internal components, offering a nominal rating of 40 microns and an absolute rating of 63 microns. This design is effective at capturing particles that might bypass the main system filter or result from component failure, providing unnoticed protection during regular operation but acting as a safeguard against sudden failures. The Depth Type elements incorporate pleated microglass media with clear zinc-coated components, available in nominal ranges of 3, 10, and 25 microns. These elements have specific Beta ratios as detailed in performance curves. The FLJAXDV model fits into cavity T18A, part of Series 4, and supports a capacity of up to 80 gpm (320 L/min) with a maximum operating pressure of 5000 psi (350 bar). Installation requires a valve hex size of 1-5/8 inches (41.3 mm) with torque specifications between 350 to 375 lbf-ft (475 to 508 Nm). For maintenance, the cartridge seal kit is made from Viton material with part number 990018006.
