SUN HYDRAULICS
FRDAOAN
$97.00 USD
- SUN HYDRAULICS
- Material:FRDAOAN
- Model:FRDA-OAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FRDAOAN (Material Number: FRDAOAN) is a bypass-restrictive, fixed-orifice, priority flow control valve designed to manage hydraulic flow efficiently. This valve takes an input flow at port 1 and prioritizes the flow to port 3. If the input exceeds the priority requirements, the surplus is directed through port 2, which can be utilized in a secondary circuit. Users must specify a flow rating, with factory-set ratings accurate within 10% of the requested setting. The maximum pressure at port 3 should not exceed 3000 psi (210 bar). Both priority and bypass flows are operational up to the system's maximum pressure, with priority remaining stable despite input variations. Notably, bypass flow becomes available only after meeting priority needs, and pressure at port 2 can exceed that at port 3. The sharp-edged orifice design minimizes variations due to viscosity changes, and an adjustable control option allows for up to a 25% variation from the nominal preset flow through three turns of an adjustment screw. The Sun floating style construction reduces internal binding risks due to installation torque or machining variations. This valve fits into cavity T-2A and belongs to series 2 with a capacity of 12 gpm (45 L/min) and can handle a maximum operating pressure of 5000 psi (350 bar). The maximum input flow is capped at 30 gpm (120 L/min). It features specific dimensions for installation torque and adjustment screws, ensuring precise application in hydraulic systems where managing multiple oil sources from one pump is necessary without overheating issues.
The Sun Hydraulics FRDAOAN (Material Number: FRDAOAN) is a bypass-restrictive, fixed-orifice, priority flow control valve designed to manage hydraulic flow efficiently. This valve takes an input flow at port 1 and prioritizes the flow to port 3. If the input exceeds the priority requirements, the surplus is directed through port 2, which can be utilized in a secondary circuit. Users must specify a flow rating, with factory-set ratings accurate within 10% of the requested setting. The maximum pressure at port 3 should not exceed 3000 psi (210 bar). Both priority and bypass flows are operational up to the system's maximum pressure, with priority remaining stable despite input variations. Notably, bypass flow becomes available only after meeting priority needs, and pressure at port 2 can exceed that at port 3. The sharp-edged orifice design minimizes variations due to viscosity changes, and an adjustable control option allows for up to a 25% variation from the nominal preset flow through three turns of an adjustment screw. The Sun floating style construction reduces internal binding risks due to installation torque or machining variations. This valve fits into cavity T-2A and belongs to series 2 with a capacity of 12 gpm (45 L/min) and can handle a maximum operating pressure of 5000 psi (350 bar). The maximum input flow is capped at 30 gpm (120 L/min). It features specific dimensions for installation torque and adjustment screws, ensuring precise application in hydraulic systems where managing multiple oil sources from one pump is necessary without overheating issues.
Bypass/restrictive, fixed-orifice, priority flow controls take an input flow at port 1 and use it to satisfy the priority flow at port 3. If the input flow exceeds the priority flow requirement, the excess is bypassed out port 2. The bypass flow may be used in a secondary circuit.
- Customer must specify a flow rating. Factory set flow ratings are within +/- 10% of the requested setting.
- Maximum pressure at port 3 should be limited to 3000 psi (210 bar).
- Both priority and bypass flow are usable up to the system operating pressure.
- Priority remains relatively constant regardless of variation in input flow.
- Bypass flow is not available until priority flow requirements are satisfied.
- Pressure at the bypass port (port 2) may exceed pressure at the priority port (port 3).
- The sharp-edged orifice design minimizes flow variations due to viscosity changes.
- A tuneable adjustment control option provides up to +/- 25% variation from the nominal factory pre-set flow. Adjustment is done with +/- 3 turns of the adjust screw. Screw in (CW) to increase flow.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-2A |
| Series | 2 |
| Capacity | 12 gpm45 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Input Flow | 30 gpm120 L/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Adjustment Screw Internal Hex Size | 5/32 in.4 mm |
| Locknut Hex Size | 9/16 in.15 mm |
| Locknut Torque | 80 - 90 lbf in.9 - 10 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-202-006 |
