SUN HYDRAULICS
FREAKAV
$205.31 USD
- SUN HYDRAULICS
- Material:FREAKAV
- Model:FREA-KAV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FREAKAV (Material Number: FREAKAV) is a precision-engineered bypass-restrictive, fixed-orifice, priority flow control valve designed to manage hydraulic flow efficiently. This valve takes input flow at port 1 and prioritizes it to port 3, while any excess flow is bypassed through port 2 for secondary circuit usage. It is crucial for users to specify the desired flow rating, as factory settings are accurate within 10% of the requested specifications. The valve can handle a maximum pressure of up to 3000 psi at port 3 and offers a tuneable adjustment control with a variation of up to 22% from the nominal factory preset flow. Adjustments can be made using three turns of the adjust screw, where screwing clockwise increases the flow. Both priority and bypass flows are operable up to system pressure limits, with priority flows remaining stable despite variations in input flow. The sharp-edged orifice design ensures minimal flow variation due to viscosity changes, enhancing its performance consistency. The valve's construction incorporates Sun's floating style design, reducing the risk of internal parts binding from excessive installation torque or machining variations. It fits into cavity T-17A and belongs to Series 3 with a capacity of up to 25 gpm (95 L/min). The maximum operating pressure is rated at 5000 psi (350 bar), with an input flow capacity reaching up to 60 gpm (240 L/min). For installation, it requires a torque setting between 150-160 lbf ft (203-217 Nm). This model weighs approximately 1.25 lb (0.60 kg) and uses Viton for its seal kit cartridge.
The Sun Hydraulics FREAKAV (Material Number: FREAKAV) is a precision-engineered bypass-restrictive, fixed-orifice, priority flow control valve designed to manage hydraulic flow efficiently. This valve takes input flow at port 1 and prioritizes it to port 3, while any excess flow is bypassed through port 2 for secondary circuit usage. It is crucial for users to specify the desired flow rating, as factory settings are accurate within 10% of the requested specifications. The valve can handle a maximum pressure of up to 3000 psi at port 3 and offers a tuneable adjustment control with a variation of up to 22% from the nominal factory preset flow. Adjustments can be made using three turns of the adjust screw, where screwing clockwise increases the flow. Both priority and bypass flows are operable up to system pressure limits, with priority flows remaining stable despite variations in input flow. The sharp-edged orifice design ensures minimal flow variation due to viscosity changes, enhancing its performance consistency. The valve's construction incorporates Sun's floating style design, reducing the risk of internal parts binding from excessive installation torque or machining variations. It fits into cavity T-17A and belongs to Series 3 with a capacity of up to 25 gpm (95 L/min). The maximum operating pressure is rated at 5000 psi (350 bar), with an input flow capacity reaching up to 60 gpm (240 L/min). For installation, it requires a torque setting between 150-160 lbf ft (203-217 Nm). This model weighs approximately 1.25 lb (0.60 kg) and uses Viton for its seal kit cartridge.
Bypass/restrictive, fixed-orifice, priority flow controls take an input flow at port 1 and use it to satisfy the priority flow at port 3. If the input flow exceeds the priority flow requirement, the excess is bypassed out port 2. The bypass flow may be used in a secondary circuit.
- Customer must specify a flow rating. Factory set flow ratings are within +/- 10% of the requested setting.
- Maximum pressure at port 3 should be limited to 3000 psi (210 bar).
- A tuneable adjustment control option provides up to +/- 22% variation from the nominal factory pre-set flow. Adjustment is done with +/- 3 turns of the adjust screw. Screw in (CW) to increase flow.
- Both priority and bypass flow are usable up to the system operating pressure.
- Priority remains relatively constant regardless of variation in input flow.
- Bypass flow is not available until priority flow requirements are satisfied.
- Pressure at the bypass port (port 2) may exceed pressure at the priority port (port 3).
- The sharp-edged orifice design minimizes flow variations due to viscosity changes.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-17A |
| Series | 3 |
| Capacity | 25 gpm95 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Input Flow | 60 gpm240 L/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Adjustment Screw Internal Hex Size | 5/32 in.4 mm |
| Locknut Hex Size | 9/16 in.15 mm |
| Locknut Torque | 80 - 90 lbf in.9 - 10 Nm |
| Model Weight | 1.25 lb0,60 kg |
| Seal kit - Cartridge | Viton: 990-017-006 |
