SUN HYDRAULICS
FREAXAN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FREAXAN (Material Number: FREAXAN) is a bypass-restrictive, fixed-orifice, priority flow control valve designed to manage hydraulic flow efficiently. It takes an input flow at port 1 and prioritizes the output at port 3, with any excess flow bypassed to port 2 for potential use in secondary circuits. The flow rating must be specified by the customer and is factory set within a 10% range of the requested setting. The valve's maximum pressure at port 3 is limited to 3000 psi (210 bar), while its maximum operating pressure can reach up to 5000 psi (350 bar). The FREAXAN can handle a capacity of up to 25 gpm (95 L/min) and a maximum input flow of 60 gpm (240 L/min). This model features a tunable adjustment control option that allows for up to a 22% variation from the nominal factory preset flow, adjustable via three turns of an internal hex screw. Both priority and bypass flows are usable up to system operating pressure, with priority remaining relatively constant regardless of input variation. However, bypass flow only becomes available once priority requirements are met. The design incorporates Sun's floating style construction, minimizing risks of internal binding due to excessive torque or machining variations. The sharp-edged orifice design effectively reduces flow variations caused by viscosity changes. Installation requires specific torque settings: valve installation torque should be between 150-160 lbf ft (203-217 Nm), with locknut torque set at 80-90 lbf in (9-10 Nm). The FREAXAN model weighs approximately 1.25 lb (0.60 kg) and comes equipped with Viton seals as part of its cartridge assembly.
