SUN HYDRAULICS
FVEAKBV
$299.23 USD
- SUN HYDRAULICS
- Material:FVEAKBV
- Model:FVEA-KBV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FVEAKBV (FVEAKBV) is a versatile ventable, bypass-restrictive, fixed-orifice priority flow control valve designed to manage hydraulic flow with precision. This valve directs input flow from port 1 to meet the priority flow requirements at port 3. Should the input exceed the priority demand, excess flow is bypassed through port 2, which can be utilized in secondary circuits. Remote control is enabled via a vent port at port 4. The valve's factory-set flow ratings are accurate within 10% of the requested setting, and adjustments can be made for up to a 25% variation using an internal adjustment screw. The maximum pressure at port 3 should not exceed 3000 psi (210 bar), while both priority and bypass flows are operable up to system pressure limits. The FVEAKBV model incorporates Sun's floating style construction, reducing risks of internal binding due to installation torque or machining variations. With a capacity of up to 25 gpm (95 L/min) and a maximum input flow of 60 gpm (240 L/min), it fits into a T-23A cavity and withstands operating pressures up to 5000 psi (350 bar). The valve\u2019s sharp-edged orifice design minimizes viscosity-related flow variations, ensuring consistent performance across varying conditions. Priority remains stable despite input fluctuations; however, bypass flow only activates after satisfying the priority requirement unless vented. This model weighs approximately 1.40 lb (0.65 kg) and utilizes Viton seals for durability under demanding conditions. It is suitable for applications requiring precise flow management and remote operation capabilities in hydraulic systems where maintaining distinct circuit priorities is essential.
The Sun Hydraulics FVEAKBV (FVEAKBV) is a versatile ventable, bypass-restrictive, fixed-orifice priority flow control valve designed to manage hydraulic flow with precision. This valve directs input flow from port 1 to meet the priority flow requirements at port 3. Should the input exceed the priority demand, excess flow is bypassed through port 2, which can be utilized in secondary circuits. Remote control is enabled via a vent port at port 4. The valve's factory-set flow ratings are accurate within 10% of the requested setting, and adjustments can be made for up to a 25% variation using an internal adjustment screw. The maximum pressure at port 3 should not exceed 3000 psi (210 bar), while both priority and bypass flows are operable up to system pressure limits. The FVEAKBV model incorporates Sun's floating style construction, reducing risks of internal binding due to installation torque or machining variations. With a capacity of up to 25 gpm (95 L/min) and a maximum input flow of 60 gpm (240 L/min), it fits into a T-23A cavity and withstands operating pressures up to 5000 psi (350 bar). The valve\u2019s sharp-edged orifice design minimizes viscosity-related flow variations, ensuring consistent performance across varying conditions. Priority remains stable despite input fluctuations; however, bypass flow only activates after satisfying the priority requirement unless vented. This model weighs approximately 1.40 lb (0.65 kg) and utilizes Viton seals for durability under demanding conditions. It is suitable for applications requiring precise flow management and remote operation capabilities in hydraulic systems where maintaining distinct circuit priorities is essential.
Ventable, bypass/restrictive, fixed-orifice, priority flow controls take an input flow at port 1 and use it to satisfy the priority flow at port 3. If the input flow exceeds the priority flow requirement, the excess is bypassed out port 2. The bypass flow may be used in a secondary circuit. A vent port (port 4) allows these valves to be controlled remotely.
- Customer must specify a flow rating. Factory set flow ratings are within +/- 10% of the requested setting.
- Using a pressure control on port 4 will limit the pressure at the priority port (port 3). If pressure on the bypass port (port 2) exceeds the setting of the pressure control, priority flow will be shut off and all the flow will go out the bypass port.
- Maximum pressure at port 3 should be limited to 3000 psi (210 bar).
- Both priority and bypass flow are usable up to the system operating pressure.
- Priority remains relatively constant regardless of variation in input flow.
- Bypass flow is not available until priority flow requirements are satisfied, except when the valve is vented. When port 4 (vent) is open, all flow diverts to port 2 if pressure at port 1 (inlet) is 150 psi (10,5 bar) or higher.
- Pressure at the bypass port (port 2) may exceed pressure at the priority port (port 3).
- The sharp-edged orifice design minimizes flow variations due to viscosity changes.
- A tuneable adjustment control option provides up to +/- 25% variation from the nominal factory pre-set flow. Adjustment is done with +/- 3 turns of the adjust screw. Screw in (CW) to increase flow.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-23A |
| Series | 3 |
| Capacity | 25 gpm95 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Nominal Vent Flow | 46 in³/min.0,75 L/min. |
| Maximum Input Flow | 60 gpm240 L/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Adjustment Screw Internal Hex Size | 5/32 in.4 mm |
| Locknut Hex Size | 9/16 in.15 mm |
| Locknut Torque | 80 - 90 lbf in.9 - 10 Nm |
| Model Weight | 1.40 lb0,65 kg |
| Seal kit - Cartridge | Viton: 990-023-006 |
