SUN HYDRAULICS
HEQ
$195.38 USD
- SUN HYDRAULICS
- Material:HEQ
- Summary:Manifold
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics HEQ (Material Number: HEQ) is a line mount manifold specifically designed for high-capacity applications. It features a unique ninety-degree body type with a high-capacity port 3 and an additional gauge port, facilitating versatile hydraulic system configurations. The manifold includes open cavities, specifically the T-17A cavity, and accommodates a port size of 1 1/4 Code 61. Constructed from 6061-T651 aluminum, this manifold offers excellent corrosion resistance and durability without the need for anodizing, thus maintaining its structural integrity over time. It is important to note that this manifold is not rated for pressures exceeding 3000 psi (210 bar), regardless of port type or size. This product serves as efficient plumbing within hydraulic systems, providing reliable performance in various applications where robust flow management is required.
The Sun Hydraulics HEQ (Material Number: HEQ) is a line mount manifold specifically designed for high-capacity applications. It features a unique ninety-degree body type with a high-capacity port 3 and an additional gauge port, facilitating versatile hydraulic system configurations. The manifold includes open cavities, specifically the T-17A cavity, and accommodates a port size of 1 1/4 Code 61. Constructed from 6061-T651 aluminum, this manifold offers excellent corrosion resistance and durability without the need for anodizing, thus maintaining its structural integrity over time. It is important to note that this manifold is not rated for pressures exceeding 3000 psi (210 bar), regardless of port type or size. This product serves as efficient plumbing within hydraulic systems, providing reliable performance in various applications where robust flow management is required.
| Body Type | Line mountLine mount |
| Interface | NoneNone |
| Body Features | Ninety degree with high capacity port 3 and gauge portNinety degree with high capacity port 3 and gauge port |
| Open Cavities | 11 |
| Cavity | T-17A |
| Port Size | 1 1/4" Code 611 1/4" Code 61 |
Show FAQ
Additional Resources
- QuickDesign with SmartConnect Offers Drag-and-Drop Schematic Tool
- Standard Line Mount Manifolds for High Flow Valves
- Manufacturing Sun Cartridge Cavities
- Manifolds: Materials of Construction
- Sun's Floating Style Screw-In Cartridge
- Sun Model Code Explanation; 999-901-334
- Custom Integrated Packages from Sun
- Fluid and Temperature Recommendations
- QuickDesign & SunDesign: Sun's 3- & 5-Axis Solutions
Notes:
- Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
