SUN HYDRAULICS
IAD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics IAD (Material Number: IAD) is a line mount manifold designed for hydraulic applications requiring a robust and corrosion-resistant solution. It features a ninety-degree body configuration with an integrated gauge port, allowing for convenient system monitoring. The manifold is constructed from 6061T651 aluminum, known for its strength and exceptional corrosion resistance, making it suitable for demanding environments. This model includes one open cavity with a T16A cavity type and accommodates a 3/4 NPTF port size, ensuring compatibility with various hydraulic components. It has an overall mounting hole diameter of .41 inches (10.4 mm) and utilizes through-hole mounting with one hole provided. The Sun Hydraulics IAD manifold is engineered to withstand pressures up to 3000 psi (210 bar), which is critical when designing hydraulic systems to ensure safety and reliability. Its design does not include anodization, as the inherent properties of the aluminum used provide sufficient corrosion resistance without additional treatment. This choice also avoids potential issues such as increased breakaway torque or reduced fatigue life that can result from anodizing processes. Applications of the IAD manifold are diverse, serving situations where line-mounted configurations are advantageous due to space constraints or specific system requirements. Its durable construction and thoughtful design make it ideal for integrating into complex hydraulic systems where reliability and performance are paramount.
