SUN HYDRAULICS
IEY

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics IEY (Material Number: IEY) is a line mount manifold designed for hydraulic systems, featuring a through port with an additional gauge port for enhanced monitoring capabilities. This manifold incorporates an M10x1.5 6H mounting hole thread and offers a mounting hole depth of 15.7 mm, with a total of two mounting holes available. The open cavity design is specified as T16A, providing flexibility in system configuration. It includes a single port size of 1 1/4 BSPP, which ensures compatibility with standard hydraulic connections. Constructed from 6061T651 aluminum, the IEY manifold offers excellent corrosion resistance without the need for anodizing, making it suitable for various environments where corrosion could be an issue. The use of this material also allows the manifold to maintain durability while being cost-effective and readily available in different shapes and sizes. However, it should be noted that manifolds made from aluminum are not rated for pressures exceeding 3000 psi (210 bar), regardless of the port type or size. The Sun Hydraulics IEY manifold is ideal for applications requiring high flow rates and robust performance in hydraulic circuits. Its design accommodates easy integration into existing systems while providing reliable performance under specified pressure conditions. The inclusion of a gauge port facilitates real-time pressure monitoring, which can be crucial for maintaining system efficiency and safety.
