SUN HYDRAULICS
LA5

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics LA5 (Material Number: LA5) is a specialized line mount hydraulic manifold designed for high-flow valve applications. This product features a ninety-degree body type with an integrated gauge port, providing efficient flow management in hydraulic systems. It is constructed with 6061T651 aluminum, known for its strength, cost-effectiveness, corrosion resistance, and availability in various shapes and sizes. The manifold includes two mounting holes threaded with M10x1.5 6H metric models to ensure secure installation and has a depth of 15.7 mm. The design incorporates one open cavity with a T18A cavity type and ports sized at 1-14 Code 62, offering compatibility with standard hydraulic systems. This manifold is engineered to handle pressures up to 3000 psi (210 bar), making it suitable for demanding applications while maintaining structural integrity under high-pressure conditions. The choice of material ensures that it can withstand harsh environments without the need for anodizing, which could potentially compromise fatigue life due to the brittle surface that anodizing creates on aluminum. The LA5 model does not require additional surface treatment because the natural properties of the selected aluminum alloy provide sufficient corrosion resistance and durability for most industrial applications. This product is ideal for use in hydraulic systems where space constraints necessitate compact yet robust components capable of managing substantial fluid flow efficiently.
