SUN HYDRAULICS
NCFCLBN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics NCFCLBN (NCFCLBN) is a versatile needle valve with a reverse flow check, designed to regulate flow through fully adjustable orifices. This model allows for infinite adjustment from fully closed to the maximum orifice diameter, with an integral high-capacity check valve ensuring unrestricted flow from port 2 to port 1. Not pressure compensated, the valve's fixed orifice size regulates flow proportionally to the square root of the pressure differential across ports 1 and 2. It features a balanced adjustment mechanism for easy operation even under high pressures, and its sharp-edged orifice design minimizes flow variations due to viscosity changes. The floating style construction minimizes internal binding due to excessive installation torque or machining variations. The NCFCLBN fits a Cavity T-16A, Series 3 and has a capacity of 15 gpm (60 L/min) with a maximum operating pressure of 5000 psi (350 bar). The maximum valve leakage at 110 SUS (24 cSt) is limited to 5 drops/min (0.3 cc/min). The adjustment allows for up to five counterclockwise turns from fully closed to fully open. The valve hex size is 1-1/4 in. (31.8 mm), with an installation torque requirement of 150 - 160 lbf ft (203 - 217 Nm). The adjustment screw has an internal hex size of 5/32 in. (4 mm), while the locknut hex size is 9/16 in. (15 mm) with a torque specification of 80 - 90 lbf in. (9 -10 Nm). Weighing approximately 1.30 lb (0.60 kg), this model includes a Viton seal kit, part number: 990-016-006, ensuring durability and reliability in various hydraulic applications where precise flow control is essential.
