SUN HYDRAULICS
NFABKXV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics NFABKXV (Material Number: NFABKXV) is a two-port, pilot-stage needle valve specifically designed for regulating pilot flow in main-stage valves or metering input flow in low-flow applications. This cartridge is optimized for pilot flow scenarios and fits into the Sun T8A cavity, making it ideal for use with Sun's pilot-operated main-stage valves. The design eliminates the need for separate pilot lines, requiring only one cavity to accommodate both control and primary functions. It shares a common cavity with all two-position, two-way pilot stage control cartridges, allowing physical interchangeability while maintaining functionality. The valve can handle pressures up to 5000 psi (350 bar) on ports 1 and 2. The needle adjustment offers fine resolution from fully closed to fully open across three complete turns, ensuring precise control over flow rates. A locking device on the adjustment mechanism ensures consistent orifice diameters and flow rates are maintained. At shutoff, the leakage rate is less than one drop per minute. The valve has a capacity of 0.2 gpm (0.8 L/min) with an effective orifice size of 0.035 inches (0.9 mm). Installation requires a torque of 20-25 lbf-ft (27-33 Nm), and it features a hex size of 7/8 inches (22.2 mm). For sealing, the Viton seal kit with part number 990008006 is recommended to ensure optimal performance under varying conditions.
