SUN HYDRAULICS
NEEDLE CART.
NFBCKCN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics NFBCKCN (NFBCKCN) is a versatile needle valve designed to offer precise flow regulation in various hydraulic systems. This fully adjustable orifice allows for infinite adjustments from fully closed to the maximum orifice diameter, making it suitable as both a flow control and shutoff valve. The NFBCKCN is not pressure compensated, meaning the flow rate is dependent on the pressure differential between ports 1 and 2, regulated by the fixed orifice size. Its balanced adjustment mechanism ensures easy operation even under high pressures, while the sharp-edged orifice design minimizes flow variations due to changes in fluid viscosity. The valve supports bidirectional flow with a preferred path from port 1 to 2, ensuring interchangeability with other flow controls. The unit guarantees zero leakage when fully shut off. This model features Sun's floating style construction, which reduces the risk of internal part binding due to excessive installation torque or machining variations. It fits into a T-162A cavity and has a capacity of 5 gpm (20 L/min) at a maximum operating pressure of 5000 psi (350 bar). The adjustment mechanism allows for up to 5.5 counterclockwise turns from fully closed to open positions. Installation requires a torque of 20-25 lbf ft (27-33 Nm), and it utilizes an internal hex size of 5/32 inches for adjustments. The locknut requires a torque of 80-90 lbf in (9-10 Nm). Weighing just .20 lb (.10 kg), this model is compatible with systems using EPDM seals for phosphate ester fluids but should avoid petroleum-based fluids to prevent seal damage.
