SUN HYDRAULICS
NFCCOCV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics NFCCOCV (Material Number: NFCCOCV) is a versatile needle valve designed for precise flow regulation in hydraulic systems. This fully adjustable orifice allows users to control flow rates from fully closed to the maximum orifice diameter without pressure compensation. It serves dual functions as both a flow control and shutoff valve. The NFCCOCV model features a balanced adjustment mechanism, facilitating smooth adjustments even under high-pressure conditions, with a maximum operating pressure of 5000 psi (350 bar). The sharp-edged orifice design ensures minimal flow variation due to changes in fluid viscosity, while the bidirectional flow path offers flexibility in installation, with the preferred direction being from port 1 to 2 for compatibility with other flow controls. The valve's physical and functional interchangeability across all 2-port flow control cartridges means it shares the same cavity and flow path for a given frame size, although extension dimensions might vary. Importantly, when adjusted to the shutoff position, there is no leakage through the valve. For systems utilizing phosphate ester fluids, versions of this valve configured with EPDM seals are recommended; however, exposure to petroleum-based fluids can damage these seals. The NFCCOCV model fits into a Cavity T-13A and has a series capacity of 7 gpm (.19 inches or 28 L/min) with an adjustment range of up to 5.5 counterclockwise turns from fully closed to open. It requires specific installation torques: valve installation torque ranges from 30-35 lbf ft (41-47 Nm), while the locknut torque is between 80-90 lbf in (9-10 Nm). Additionally, it includes an internal hex size for adjustment screw at 5/32 inches (4 mm) and a locknut hex size of 9/16 inches (15 mm). The product weighs approximately .30 lb (.15 kg) and can be sealed with Viton using seal kit number 990010006.
