SUN HYDRAULICS
PA5

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics PA5 (Material Number: PA5) is a line mount manifold designed for hydraulic systems requiring efficient fluid control and distribution. This model features a ninety-degree configuration with a gauge port, providing versatility in various hydraulic applications. It is equipped with M10x1.5 6H metric models for mounting holes, accommodating two mounting holes at a depth of 15.7 mm (.62 inches). The manifold includes one open cavity, identified as T-23A, and utilizes port size 1 with a 14 Code 62 specification. Constructed from 6061-T651 aluminum, the PA5 offers excellent corrosion resistance and structural integrity while maintaining lightweight properties suitable for high-performance environments. The manifold's design ensures compatibility with high flow valves, making it ideal for use in complex hydraulic circuits where precise control and reliability are paramount. It is important to note that the maximum system pressure should be carefully considered, as aluminum manifolds like this one are not rated for pressures exceeding 3000 psi (210 bar). This product is particularly useful in applications that require robust performance without compromising on material quality or durability.
