SUN HYDRAULICS
PAE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics PAE (Material Number: PAE) is a line mount manifold designed for hydraulic applications, featuring a ninety-degree body with an integrated gauge port. Constructed from 6061T651 aluminum, this manifold is renowned for its corrosion resistance and durability, making it suitable for various demanding environments. It includes two mounting holes with a diameter of .41 inches (10.4 mm) that go through the body, allowing secure installation. The manifold is equipped with one open cavity and utilizes the T-23A cavity type. It features a 1 NPTF port size, ensuring compatibility with standard hydraulic systems. This manifold is particularly noted for its robust construction, as 6061T651 aluminum offers an excellent balance of strength and cost-efficiency while being readily available in diverse shapes and sizes. Despite not being anodized, the material's inherent corrosion resistance eliminates the need for additional protective coatings in most scenarios. However, users should be mindful of the maximum system pressure; manifolds made from aluminum like this one are not rated for pressures exceeding 3000 psi (210 bar). The design of the Sun Hydraulics PAE ensures efficient fluid handling within hydraulic systems while maintaining reliability and ease of integration into existing setups. Its construction supports high flow applications without compromising on structural integrity or performance longevity.
