SUN HYDRAULICS
PAF

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics PAF (Material Number: PAF) is a line mount manifold designed for hydraulic systems requiring a compact and efficient solution. This ninety-degree manifold features a gauge port, providing easy access for pressure monitoring. It is constructed from 6061-T651 aluminum, known for its strength, corrosion resistance, and availability in various shapes and sizes. The manifold has a mounting hole diameter of .41 inches (10.4 mm) with two through-holes to facilitate secure installation. It is designed with one open cavity and utilizes the T-23A cavity type. The port size is specified as 1 1/4 NPTF, making it compatible with standard hydraulic fittings. This manifold is particularly suitable for applications where space constraints are an issue or where ease of maintenance is desired due to its accessible gauge port. The use of high-quality aluminum ensures that the manifold can withstand environmental challenges without the need for anodizing, which can introduce issues such as increased breakaway torque and reduced fatigue life. However, users must consider the maximum system pressure when integrating this component, as aluminum manifolds are not rated for pressures exceeding 3000 psi (210 bar). The Sun Hydraulics PAF model provides an effective solution for managing hydraulic flow in various system configurations while maintaining durability and reliability under specified conditions.
