SUN HYDRAULICS
LINE MOUNT BODY
PAN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics PAN (Material Number: PAN) is a line mount hydraulic manifold designed with a ninety-degree body featuring a gauge port. This component is crafted to accommodate high flow valves, making it suitable for applications requiring efficient fluid management within hydraulic systems. The manifold includes two mounting holes with a diameter of 0.41 inches (10.4 mm), allowing for secure installation in various setups. It features one open cavity, identified as T-23A, and has SAE 20 port sizes, which are standard in many hydraulic systems to ensure compatibility and ease of integration. Constructed from 6061-T651 aluminum, the manifold offers excellent corrosion resistance and durability without the need for anodizing, which can negatively impact fatigue life by introducing cracks under pressure. This makes it reliable under operating pressures up to 3000 psi (210 bar). The choice of material also ensures that the manifold remains cost-effective while maintaining structural integrity over time. The PAN model is particularly useful in environments where space constraints or specific directional flow requirements dictate the need for a compact and efficient manifold solution. Its design allows for easy connection and disconnection of hydraulic components, facilitating maintenance and reconfiguration as needed. Overall, the Sun Hydraulics PAN provides a robust solution for managing high-pressure fluid dynamics in various hydraulic applications.
