SUN HYDRAULICS
PAY

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics PAY (PAY) is a robust line mount manifold designed for hydraulic applications requiring a 90-degree configuration with an integrated gauge port. This model features a body type specifically tailored for line mounting without any additional interface requirements. The manifold is constructed from 6061-T651 aluminum, known for its excellent corrosion resistance and strength, making it suitable for various environments. It includes two mounting holes with a diameter of 0.41 inches (10.4 mm) that go through the entire depth of the body, allowing secure attachment to compatible systems. The PAY model offers one open cavity, designated as T-23A, which can accommodate various hydraulic components as needed. The port size is specified at 1-1/4 BSPP, ensuring compatibility with standard hydraulic fittings and facilitating straightforward integration into existing hydraulic systems. The design of this manifold emphasizes ease of use and reliability in demanding applications, providing an efficient flow path while maintaining structural integrity under pressures up to 3000 psi (210 bar). This makes it an ideal choice for systems operating within these pressure limits. The use of high-quality aluminum ensures that the manifold remains lightweight yet durable, offering long-term performance without the need for additional treatments like anodizing. This choice not only reduces production costs but also minimizes potential issues related to increased torque or fatigue life that can occur with anodized surfaces. Overall, the Sun Hydraulics PAY model is engineered to deliver dependable performance in hydraulic systems requiring efficient fluid control within specified pressure parameters.
