The Sun Hydraulics PPDFCNN (PPDFCNN) is a pilot-operated, pressure-reducing/relieving valve designed to maintain a consistent reduced pressure from a higher primary pressure. This valve features a unique design where the main stage orifice is drilled into the piston, enhancing its durability in demanding applications. It has a maximum operating pressure of 5000 psi (350 bar) and supports a flow capacity of up to 10 gpm (40 L/min). The valve is suitable for applications where stable and low-hysteresis pressure control is essential, but it is not intended for fast-acting scenarios\u2014direct acting valves are recommended for those. The PPDFCNN model incorporates Sun's floating style construction to prevent internal parts from binding due to installation torque or machining variations. Additionally, it offers full-flow relief from port 1 to tank port 3 and allows reverse flow from reduced pressure port 1 to inlet port 2, although this may cause the main spool to close. For circuits requiring reverse free flow, adding a separate check valve is advised. The valve's installation requires specific torques: 30-35 lbf ft (41-47 Nm) for the valve itself and 80-90 lbf in (9-10 Nm) for the locknut. It also features an internal hex size adjustment screw of 5/32 in (4 mm). The PPDFCNN model weighs approximately .30 lb (.15 kg) and utilizes Viton seals with seal kit number 990011006 available for maintenance purposes.

Pilot-operated, pressure reducing/relieving valves reduce a high primary pressure at the inlet (port 2) to a constant reduced pressure at port 1, with a full-flow relief function from port 1 to tank (port 3).

  • These valves have the main stage orifice drilled into the piston rather than a staked-in orifice. This allows the valve to survive physically demanding applications.
  • Maximum pressure at port 3 should be limited to 3000 psi (210 bar).
  • Pressure at port 3 is directly additive to the valve setting at a 1:1 ratio and should not exceed 3000 psi (210 bar).
  • Pilot operated reducing, reducing/relieving valves by nature are not fast acting valves. For superior dynamic response, consider direct acting valves.
  • Recommended maximum inlet pressure is determined by the adjustment range. Ranges D, E, N, and Q are tested with a 2000 psi (140 bar) maximum differential between inlet and reduced pressure. Ranges A, B, and H are tested with a 3000 psi (210 bar) maximum differential between inlet and reduced pressure. Ranges C and W are tested with 5000 psi (350 bar) of inlet pressure.
  • Pilot operated valves exhibit exceptionally flat pressure/flow characteristics, are very stable and have low hysteresis.
  • Full reverse flow from reduced pressure (port 1) to inlet (port 2) may cause the main spool to close. If reverse free flow is required in the circuit, consider adding a separate check valve to the circuit.
  • If pilot flow consumption is critical, consider using direct acting reducing/relieving valves.
  • All three-port pressure reducing and reducing/relieving cartridges are physically interchangeable (i.e. same flow path, same cavity for a given frame size). When considering mounting configurations, it is sometimes recommended that a full capacity return line (port 3) be used with reducing/relieving cartridges.
  • W and Y controls (where applicable) can be specified with or without a special setting. When no special setting is specified, the valve is adjustable throughout its full range using the W or Y control. When a special setting is specified, this setting represents the maximum setting of the valve.
  • Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.

CavityT-11A
Series1
Capacity10 gpm40 L/min.
Factory Pressure Settings Established atblocked control port (dead headed)blocked control port (dead headed)
Maximum Operating Pressure5000 psi350 bar
Control Pilot Flow7 - 10 in³/min.0,11 - 0,16 L/min.
Adjustment - Number of Clockwise Turns to Increase Setting55
Valve Hex Size7/8 in.22,2 mm
Valve Installation Torque30 - 35 lbf ft41 - 47 Nm
Adjustment Screw Internal Hex Size5/32 in.4 mm
Locknut Hex Size9/16 in.15 mm
Locknut Torque80 - 90 lbf in.9 - 10 Nm
Model Weight.30 lb0,15 kg
Seal kit - CartridgeViton: 990-011-006

Show FAQ

Additional Resources



Notes:
  • For Series 1 cartridges configured with an O control (panel mount handknob), a .75 in. (19 mm) diameter hole is required in the panel.
