SUN HYDRAULICS
QA5

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics QA5 (QA5) is a line mount hydraulic manifold designed for flexible and efficient fluid control in various hydraulic systems. This model features a ninety-degree body with an integrated gauge port, making it ideal for applications requiring precise pressure monitoring and control. It accommodates one open cavity and is compatible with the T-24A cavity type, ensuring seamless integration with other hydraulic components. The manifold includes two M10x1.5 6H metric threaded mounting holes, each with a depth of 15.7 mm (.62 inches), to ensure secure installation. Additionally, it supports port sizes of 1 1/4 Code 62, catering to high-flow requirements in hydraulic circuits. Constructed from 6061-T651 aluminum, the QA5 manifold offers excellent corrosion resistance without the need for anodizing, maintaining structural integrity even in challenging environments. This choice of material also ensures that the manifold remains lightweight yet robust enough to handle pressures up to 3000 psi (210 bar). The design prioritizes ease of use and reliability by eliminating unnecessary processes like anodizing, which can introduce complications such as increased breakaway torque and reduced fatigue life. Overall, the Sun Hydraulics QA5 manifold provides a reliable solution for managing fluid flow in complex hydraulic systems while ensuring durability and performance consistency across various applications.
