SUN HYDRAULICS
QCX

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics QCX (Material Number: QCX) is a line mount manifold designed for hydraulic systems requiring efficient fluid control and distribution. This model features a ninety-degree body type with no specific interface, making it versatile for various applications. It includes two mounting holes with a diameter of 0.41 inches (10.4 mm) that extend through the body, ensuring secure installation and stability in operational environments. The QCX manifold is equipped with one open cavity and utilizes the T-24A cavity type, which accommodates specific cartridge valves for customized hydraulic solutions. The port size of the manifold is 1 BSPP, which is a common thread standard allowing for seamless integration into existing hydraulic systems without the need for additional adapters or modifications. Constructed from 6061T651 aluminum, this manifold offers excellent corrosion resistance and durability under standard operating conditions, although it is not anodized to maintain its natural properties and avoid potential issues such as increased breakaway torque or reduced fatigue life. This product is particularly suitable for high-flow valve applications where reliable performance and longevity are critical. It provides an efficient solution for managing hydraulic fluid flow within various machinery or equipment setups, contributing to optimized system performance and maintenance ease. When using this manifold, it is important to consider the maximum system pressure as aluminum manifolds are not rated for pressures exceeding 3000 psi (210 bar).
