SUN HYDRAULICS
RBAALBV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RBAALBV (RBAALBV) is a direct-acting pilot relief cartridge designed to remotely control the pressure setting of other pilot-operated valves. This product is particularly suitable for load-holding applications, providing reliable performance with a maximum operating pressure of 5000 psi (350 bar). The valve incorporates a main stage orifice protected by a 150-micron stainless steel screen, ensuring durability and longevity in various environments. Notably, this cartridge is corrosion-resistant, with options for external stainless steel components or zinc-nickel plating, making it ideal for use in corrosive conditions. One of the key features of this valve is its ability to handle back pressure on the tank port (port 2), which directly adds to the valve setting at a 1:1 ratio. The RBAALBV model can be configured with EPDM seals for systems using phosphate ester fluids; however, exposure to petroleum-based fluids could damage these seals. Additionally, W and Y controls are available with or without special settings, allowing for full-range adjustability or fixed maximum settings as needed. Installation and adjustment are straightforward due to its floating style construction that minimizes internal binding risks. The valve's compact design includes a cavity T-3A series with a capacity of 0.5 gpm (2 L/min) and features such as an adjustment screw internal hex size of 5/32 inch (4 mm) and locknut torque specifications between 80-90 lbf-in (9-10 Nm). With its robust construction and precise control capabilities, the Sun Hydraulics RBAALBV is an excellent choice for applications requiring reliable pressure management in demanding environments.
