SUN HYDRAULICS
RBAEODV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RBAEODV (RBAEODV) is a two-port, pilot-stage, direct-acting relief cartridge designed for precise pressure regulation in hydraulic systems. This normally closed valve opens a flow path from port 1 to port 2 when the inlet pressure at port 1 surpasses the spring force setting, effectively managing system pressure. Utilizing the Sun T8A two-port cavity, this cartridge is ideal for integration with Sun's main stage pilot or vent-to-operate cartridges, eliminating the need for separate pilot lines and simplifying installation by requiring only one cavity to fulfill both control and primary functions. The valve features a hardened poppet and seat to ensure consistent operation, low leakage rates, and enhanced wear characteristics. Ports 1 and 2 can handle pressures up to 5000 psi (350 bar), with backpressure at port 2 directly adding to the pressure setting at port 1. The valve's floating style construction minimizes binding risks due to excessive torque or machining variations. It offers a capacity of up to 2.5 gpm (10 L/min) with a typical response time of 2 ms and maximum leakage of 15 drops/minute (1 cc/min). Installation requires specific torque values: main stage valve should be torqued first followed by the T8A pilot control section. The RBAEODV is equipped with EPDM seals suitable for systems using phosphate ester fluids; however, exposure to petroleum-based fluids can damage these seals. This cartridge includes an internal hex adjustment screw size of 5/32 in (4 mm) and a locknut requiring torque between 80-90 lbf-in (9-10 Nm). It provides reliable performance as a direct-acting relief valve, suitable for applications necessitating rapid response and robust operation in demanding environments.
