SUN HYDRAULICS
RBFACCV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RBFACCV (RBFACCV) is a bidirectional, direct-acting relief cartridge designed to protect hydraulic components from pressure transients. This normally closed, pressure-limiting valve begins to open and throttle flow when the pressure differential between ports 1 and 2 exceeds the valve setting, effectively limiting the pressure rise regardless of flow direction. Both directions exhibit similar performance characteristics. The internal modulation of this valve makes it resistant to cavitation-related issues such as noise and manifold erosion. Adjustment of the valve requires that the pressure be removed, or port 2 can be used for setting adjustments. The valve is relatively insensitive to changes in oil temperature and contamination, ensuring consistent performance across varying conditions. For optimal repeatability, select a spring range where the desired relief setting is midrange to high between its minimum and maximum pressures. All two-port relief cartridges are interchangeable with the same flow path and cavity for a given frame size due to their Sun floating style construction, which minimizes internal binding risks. The RBFACCV features a T-3A cavity series with a capacity of 30 gpm (120 L/min) and operates at a maximum pressure of 5000 psi (350 bar). Its typical response time is 2 ms, with maximum leakage at reseat limited to 30 drops/minute. The valve reseats at 85% of its set value with a hysteresis of about 3%. For installation, it requires a torque specification between 45-50 lbf ft (61-68 Nm), using Viton seals available in kit number 990303006.
