SUN HYDRAULICS
RBFACWV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RBFACWV (RBFACWV) is a bidirectional, direct-acting relief cartridge valve designed to protect hydraulic components from pressure transients by limiting pressure rise. This normally closed, pressure-limiting valve opens when the pressure differential between ports 1 and 2 surpasses the valve setting, throttling flow to manage pressure regardless of direction. Both directions exhibit similar settings and performance. Its internal modulation helps prevent issues like cavitation-induced noise and manifold erosion. The valve's adjust screw seals are exposed to port 1 pressure; thus, adjustments should be made only when pressure is released or via port 2. It maintains performance despite varying oil temperatures and contamination levels. Selecting a spring range with a relief setting in the mid-to-high range ensures optimal repeatability. The Sun floating style construction minimizes internal binding risks during installation or due to machining variations. The RBFACWV features a T-3A cavity, Series 2 capacity of 30 gpm (120 L/min), maximum operating pressure of 5000 psi (350 bar), typical response time of 2 ms, maximum leakage at reseat of 30 drops/minute, and reseat at 85% of the setting with a hysteresis of \u00b13%. Adjustments require approximately five clockwise turns for increased settings. Installation requires a torque of 45\u201350 lbf\u00b7ft (61\u201368 Nm) with a hex size of 1-1/8 inches (28.6 mm). The Viton seal kit for this cartridge is part number 990303006.
