SUN HYDRAULICS
RDBALBE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RDBALBE (RDBALBE) is a direct-acting relief cartridge designed to protect hydraulic components from pressure transients. This normally closed, pressure-limiting valve opens when the inlet port pressure reaches the set point, directing flow to the tank port to limit pressure rise. Notable for its smooth and quiet operation, this valve is essentially zero-leak, dirt tolerant, immune to silting, and offers rapid response times. It features a floating style construction that minimizes internal binding due to installation torque or machining variations. The RDBALBE model is physically and functionally interchangeable with other 2-port relief cartridges within the same frame size and flow path. It can handle maximum pressure at port 2 and is suitable for cross-port relief circuits. The valve's adjustment screw seals are exposed to system pressure, necessitating pressure removal for adjustments. It maintains performance consistency despite varying oil temperatures and contamination levels. Designed for load-holding applications, this cartridge valve accommodates backpressure at a 1:1 ratio with the valve setting. When configured with EPDM seals, it is compatible with systems using phosphate ester fluids but not petroleum-based fluids or lubricants. The valve has a capacity of 12 gpm (45 L/min), a maximum operating pressure of 5000 psi (350 bar), and typical response time of 2 ms. Its reseat capability is at 85% of the setting, with minimal leakage upon reseat. For optimal performance, select a spring range where desired relief settings are midrange to high between minimum and maximum pressures. The RDBALBE's specifications include a cavity type T-162A Series 0, adjustment capabilities via an internal hex screw, and specific torque requirements for installation and locknut adjustments.
