SUN HYDRAULICS
RDBXXAN

$51.33 USD

SUN HYDRAULICS
Material:RDBXXAN
Model:RDBX-XAN
Summary:Cartridge

Quantity in stock: 0

Note: Sales tax, and shipping will be calculated at checkout.

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RDBXXAN (RDBXXAN) is a versatile and reliable cartridge valve designed for precise pressure control in hydraulic systems. This model fits into a T-162A cavity and features a hex size of 3/4 inch (19.1 mm), with an installation torque ranging from 20 to 25 lbf ft (27 to 33 Nm). It comes with a Viton seal kit, part number 990162006, ensuring durability and compatibility with various hydraulic fluids. The RDBXXAN valve is engineered for applications requiring accurate pressure regulation, making it suitable for use in systems where overpressure prevention or pressure regulation is critical. Its direct-acting design provides fast response times, high dirt tolerance, stability, and robustness, making it ideal for preventing overpressure situations. Additionally, the valve's construction allows for easy installation and maintenance within hydraulic circuits. The Sun Hydraulics RDBXXAN cartridge valve is a reliable component that enhances system safety and efficiency by offering consistent performance under demanding conditions.

Description

Cavity	T-162A
Series	0
Valve Hex Size	3/4 in.19,1 mm
Valve Installation Torque	20 - 25 lbf ft27 - 33 Nm
Seal kit - Cartridge	Viton: 990-162-006

Show FAQ

What are the tolerances on pressure settings for Sun's pressure control valves?	Pressure setting tolerances are listed in our Performance Data page. A link to this page can also be found in the Additional Resources tab of the applicable product page.
How big is a drop of hydraulic oil?	There are exactly 250 Sun drops in a cubic inch or 15 in a cc.
Can I use a kick-down relief for my system relief?	Maybe not. We build in a good amount of overlap in the kick-down reliefs to prevent false tripping. This means they are not as fast as our standard pilot-operated reliefs. A direct-acting relief valve set just above the kick-down relief valve would be good insurance.
Direct acting or pilot operated - what do I use?	Direct-acting valves are used to prevent over pressure, and pilot-operated valves are used to regulate pressure. If you are unsure, use a direct-acting valve. Sun's direct acting valves are very fast, dirt tolerant, stable, and robust. Sun's pilot-operated valves are moderately fast, they have a low pressure rise vs. flow curve, and they are easy to adjust.
Where would I use a kick-down relief?	One graphic example is on a portable grain auger for silos. When the farmer gets caught in the auger the kick-down relief trips and allows him to escape.
