SUN HYDRAULICS
RDDA3DN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RDDA3DN (RDDA3DN) is a nonadjustable direct-acting relief cartridge designed to protect hydraulic components from pressure transients. This valve is normally closed and functions as a pressure-limiting device, opening to tank port 2 when the inlet port 1 pressure reaches the set threshold. It throttles flow to control pressure rise effectively. The RDDA3DN is characterized by its smooth and quiet operation, essentially zero leakage, dirt tolerance, immunity to silting, and rapid response time of approximately 2 milliseconds. Customers must specify the desired setting, which will be factory-set and tamper-proof. This cartridge can handle maximum pressure at port 2 and is suitable for cross-port relief circuits and load-holding applications. It remains relatively insensitive to variations in oil temperature and contamination. To ensure maximum repeatability, it is recommended to select a spring range where the relief setting falls between midrange and high within the minimum and maximum pressures. The back pressure on tank port 2 adds directly to the valve setting at a 1:1 ratio. All two-port relief cartridges, except pilot reliefs, are interchangeable with the same flow path and cavity for a given frame size. The Sun floating style construction minimizes internal part binding due to excessive installation torque or machining variations in cavity/cartridge interfaces. The valve features a capacity of 25 gpm (95 L/min), with factory pressure settings established at 4 gpm (15 L/min). It has a maximum operating pressure of 5000 psi (350 bar) and a reseat capability of 90% of the setting with minimal leakage at reseat levels\u201410 drops/minute (0.7 cc/min). The RDDA3DN has a valve hex size of 7/8 inch (22.2 mm) and an installation torque requirement of 30-35 lbf ft (41-47 Nm). The model weighs .30 lb (.15 kg) and uses Viton seal kits under part number: 990310006.
