SUN HYDRAULICS
RDFALEV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RDFALEV (Material Number: RDFALEV) is a direct-acting relief cartridge designed to protect hydraulic components from pressure transients by limiting pressure rise. This normally closed, pressure-limiting valve opens to the tank port when the inlet pressure reaches the valve setting, ensuring smooth and quiet operation with essentially zero leakage. The RDFALEV is dirt tolerant, immune to silting, and offers rapid response times of approximately 2 milliseconds. It is interchangeable with other 2-port relief cartridges of the same frame size and can withstand maximum pressure at port 2, making it suitable for cross-port relief circuits. This valve is particularly useful in load-holding applications and features a floating style construction that minimizes internal part binding due to installation torque or machining variations. The adjustment procedure requires removing system pressure before altering settings via an internal hex screw, with adjustments increasing setting through clockwise turns. The valve's insensitivity to oil temperature variations and contamination further enhances its reliability. Specifications include a capacity of 50 gpm (200 L/min), a maximum operating pressure of 5000 psi (350 bar), and a reseat value at 90% of the setting. The RDFALEV accommodates backpressure on the tank port at a 1:1 ratio additive to the valve setting. It can be configured with EPDM seals for systems utilizing phosphate ester fluids; however, exposure to petroleum-based fluids may damage these seals. Installation requires specific torque values for both the valve and locknut hex sizes. The Sun Hydraulics RDFALEV represents an effective solution for preventing overpressure in hydraulic systems while maintaining stability and robustness under varying operational conditions.
