SUN HYDRAULICS
RDHALDV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RDHALDV (Material Number: RDHALDV) is a direct-acting relief cartridge designed to protect hydraulic components from pressure transients. This normally closed, pressure-limiting valve opens to the tank port when the inlet port pressure reaches the preset valve setting, effectively throttling flow and limiting pressure rise. Notable for its smooth, quiet operation and essentially zero leakage, this valve is dirt tolerant, immune to silting, and offers rapid response times. It features physical and functional interchangeability among all 2-port relief cartridges with the same flow path and cavity for a given frame size. The RDHALDV can handle maximum pressures at port 2, making it suitable for cross-port relief circuits and load-holding applications. Back pressure on tank port 2 is directly additive to the valve setting at a 1:1 ratio. The valve's design includes Sun\u2019s floating style construction to minimize internal parts binding due to excessive installation torque or cavity/cartridge machining variations. It is relatively insensitive to varying oil temperatures and contamination. The adjustment process requires relieving system pressure before making changes; adjustments are made by turning an internal hex screw with specific torque settings provided for both the adjustment screw and locknut. With a capacity of 100 gpm (380 L/min) and a maximum operating pressure of 5000 psi (350 bar), this model ensures high performance with repeatability when selecting a spring range where desired relief settings are midrange to high between minimum and maximum pressures. The RDHALDV weighs 1.30 lb (0.60 kg) and uses Viton seals for durability in various applications, providing reliable protection in demanding hydraulic environments.
