SUN HYDRAULICS
RDJALBV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RDJALBV (Material Number: RDJALBV) is a direct-acting relief cartridge valve designed to protect hydraulic components from pressure transients. This normally closed, pressure-limiting valve opens to the tank port when the inlet port pressure reaches the valve setting, effectively throttling flow to limit pressure rise. Known for its smooth and quiet operation, this valve is essentially zero-leak and dirt tolerant, making it highly reliable and fast in response. It features a 2-port design that allows for physical and functional interchangeability with other relief cartridges of the same frame size and flow path. The RDJALBV can handle a maximum operating pressure of up to 5000 psi (350 bar) and has a capacity of 200 gpm (760 L/min). It is suitable for cross-port relief circuits and load-holding applications. The valve's adjust screw seals are exposed to system pressure; thus, adjustments can only be made when the system is depressurized. Users are advised to select a spring range where the desired relief setting falls within midrange to high for optimal repeatability. This valve incorporates Sun's floating style construction, minimizing internal part binding due to installation torque or cavity machining variations. The RDJALBV is relatively insensitive to varying oil temperatures and contamination levels, ensuring stable performance across different conditions. Back pressure on tank port 2 directly adds to the valve setting at a 1:1 ratio. For systems using phosphate ester fluids, EPDM seals are recommended; however, exposure to petroleum-based fluids will damage these seals. The model weighs 3.30 lbs (1.50 kg), with specific installation torques provided for various components such as the adjustment screw and locknut.
