SUN HYDRAULICS
RPCCCWV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RPCCCWV (RPCCCWV) is a pilot-operated, balanced-piston relief cartridge designed for precise pressure regulation in hydraulic systems. These normally closed valves open when the inlet port pressure reaches the set valve pressure, allowing flow to the tank port and effectively managing system pressure. Notable for their accuracy, smooth operation, and moderate response speed, these cartridges are interchangeable with other 2-port relief cartridges of the same frame size. They can handle a maximum operating pressure of 5000 psi (350 bar) and have a capacity of 12 gpm (45 L/min). The RPCCCWV model accepts maximum pressure at port 2, making it suitable for cross-port relief circuits, although spool leakage should be considered in such applications. A minimum setting of 75 psi (5 bar) is required across all spring ranges. This model is not recommended for load-holding applications due to potential spool leakage. The valve's backpressure on the tank port directly adds to the valve setting at a 1:1 ratio. The main stage orifice is protected against contamination, ensuring reliable performance. This cartridge features Sun's floating style construction to reduce binding risks from installation torque or machining variations. Cartridges with EPDM seals are compatible with phosphate ester fluids; however, exposure to petroleum-based fluids can damage these seals. With an adjustment range facilitated by five clockwise turns and specific torque requirements for installation and locknut adjustments, this model ensures ease of use and adaptability in various hydraulic systems.
