SUN HYDRAULICS
RPCCKQV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RPCCKQV (RPCCKQV) is a pilot-operated, balanced piston relief cartridge designed for precise pressure regulation in hydraulic systems. These cartridges are typically closed and begin to open when the inlet port pressure reaches the valve setting, directing flow to the tank port to maintain regulated pressure. Known for their accuracy and smooth operation, these valves exhibit low pressure rise relative to flow and offer a moderately fast response time of approximately 10 milliseconds. They are suitable for use in cross-port relief circuits, accepting maximum pressure at port 2, though spool leakage should be considered in these applications. The RPCCKQV is not recommended for load-holding applications due to potential spool leakage. The valve's back pressure on the tank port is directly additive to the valve setting at a 1:1 ratio. It features a main stage orifice protected against contamination and incorporates Sun's floating style construction to reduce internal part binding from installation torque or machining variations. The cartridge has a capacity of 12 gpm (45 L/min) and can operate under pressures up to 5000 psi (350 bar). The minimum setting available is 75 psi (5 bar), with factory settings established at 4 gpm (15 L/min). For systems utilizing phosphate ester fluids, EPDM seals are available as an option; however, exposure to petroleum-based fluids will damage these seals. Installation requires specific torques: valve installation torque between 20-25 lbf ft (27-33 Nm), adjustment screw internal hex size of 5/32 in. (4 mm), locknut hex size of 1/2 in. (12.7 mm), and locknut torque between 80-90 lbf in. (9-10 Nm). The model weight is approximately .20 lb (.10 kg), making it lightweight yet robust for various hydraulic applications.
