SUN HYDRAULICS
RPEEFBN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RPEEFBN (RPEEFBN) is a fast-acting, pilot-operated, balanced piston relief cartridge designed to protect hydraulic components from pressure transients. This normally closed, pressure-limiting valve opens quickly at the expense of smoothness to throttle flow and limit pressure rise when the inlet port 1 reaches the valve setting. It features low pressure rise versus flow and operates with remarkable speed. The valve can handle maximum pressure at port 2, making it suitable for cross-port relief circuits, though spool leakage should be considered in such applications. The main stage orifice is safeguarded by a 150-micron stainless steel screen, ensuring durability and reliability. This cartridge is not recommended for load-holding applications due to potential spool leakage. Backpressure on tank port 2 directly affects the valve setting at a 1:1 ratio. All two-port relief cartridges are interchangeable in terms of flow path and cavity for a given frame size, except for pilot reliefs. The RPEEFBN incorporates Sun's floating style construction to reduce risks of internal parts binding from excessive installation torque or machining variations. The cartridge has a capacity of 25 gpm (95 L/min) and can operate at a maximum pressure of 5000 psi (350 bar). It offers a typical response time of just 2 milliseconds and minimal valve leakage at specified conditions. The adjustment mechanism allows for an increase in setting with five clockwise turns. Installation requires specific torque settings, including a valve hex size of 7/8 inch (22.2 mm) and an installation torque between 30-35 lbf ft (41-47 Nm). The model weighs approximately .30 lb (0.15 kg) and utilizes Viton seals for optimal performance under various conditions.
