SUN HYDRAULICS
RPEEFQV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RPEEFQV (RPEEFQV) is a fast-acting, pilot-operated, balanced piston relief cartridge designed for hydraulic systems to protect components from pressure transients. These normally closed, pressure-limiting valves open quickly when the inlet port pressure reaches the set point, directing flow to the tank port to limit further pressure rise. They are characterized by their rapid response time of approximately 2 milliseconds and low pressure rise versus flow. However, this speed comes at the expense of smoothness in operation. The valve can handle a maximum operating pressure of 5000 psi (350 bar) and has a capacity of 25 gpm (95 L/min). The RPEEFQV model is suitable for use in cross-port relief circuits but should be noted for potential spool leakage, making it unsuitable for load-holding applications. The main stage orifice is safeguarded by a 150-micron stainless steel screen. It features an adjustment mechanism that allows the setting to be increased with up to five clockwise turns, using an internal hex screw. The valve incorporates Sun's floating style construction to reduce risks of internal binding due to installation torque or machining variations. Installation requires a T-10A cavity with specific torque settings: valve installation torque between 30 - 35 lbf ft (41 - 47 Nm), and locknut torque between 80 - 90 lbf in (9 - 10 Nm). The valve hex size is .78 inches (22.2 mm), while the adjustment screw internal hex size is .532 inches (4 mm), and the locknut hex size is .916 inches (15 mm). This model weighs approximately .30 lb (.15 kg) and uses Viton seals with a seal kit available under part number 990010006.
