SUN HYDRAULICS
RPEEJBV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RPEEJBV (RPEEJBV) is a fast-acting, pilot-operated, balanced piston relief cartridge designed to protect hydraulic components from pressure transients. This normally closed, pressure-limiting valve opens rapidly when the inlet port pressure reaches the valve setting, directing flow to the tank port to manage pressure rise effectively. It features a low-pressure rise versus flow and operates with exceptional speed. The main stage orifice is safeguarded by a 150-micron stainless steel screen, ensuring durability and reliability in operation. While it can handle maximum pressure at port 2 and is suitable for cross-port relief circuits, users should consider spool leakage when used in such applications. It is not recommended for load-holding applications due to this leakage characteristic. The RPEEJBV incorporates Sun's floating style construction, which minimizes internal part binding caused by excessive installation torque or machining variations in the cavity/cartridge. The valve's capacity is rated at 25 gpm (95 L/min) with maximum operating pressures of up to 5000 psi (350 bar). With a typical response time of 2 ms and minimal leakage rates at specified conditions, this cartridge ensures efficient and reliable performance. Adjustment options are available through the W or Y controls, allowing for full range adjustability unless a special setting is specified. Installation requires specific torque settings: valve installation torque ranges from 30-35 lbf ft (41-47 Nm), while locknut torque should be between 80-90 lbf in (9-10 Nm). The design also supports interchangeable use among all two-port relief cartridges within its frame size, providing flexibility and ease of maintenance across various applications.
