SUN HYDRAULICS
RPEEKEV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RPEEKEV (RPEEKEV) is a fast-acting, pilot-operated, balanced piston relief cartridge designed to protect hydraulic components from pressure transients. This normally closed, pressure-limiting valve opens rapidly when the inlet port pressure reaches the set point, directing flow to the tank port to limit further pressure increase. It features low pressure rise versus flow and exceptional speed, making it ideal for applications requiring quick response times. The valve can accept maximum pressure at port 2 and is suitable for cross-port relief circuits, though spool leakage should be considered in such configurations. The main stage orifice is safeguarded by a 150-micron stainless steel screen, ensuring durability and reliability under high-pressure conditions. Notably, this cartridge is not suitable for load-holding applications due to potential spool leakage. Back pressure on the tank port directly affects the valve setting at a 1:1 ratio. All two-port relief cartridges are interchangeable in terms of flow path and cavity size within a given frame size. The RPEEKEV model incorporates Sun's floating style construction to reduce internal binding risks caused by excessive installation torque or machining variations. With a capacity of 25 gpm (95 L/min) and a maximum operating pressure of 5000 psi (350 bar), this valve provides reliable performance in demanding environments. It has a typical response time of 2 ms and minimal leakage at specified conditions. The adjustable setting can be fine-tuned using W or Y controls with up to five clockwise turns for increased settings. Installation requires specific torque values for both the valve and locknut components, ensuring secure placement within hydraulic systems.
