SUN HYDRAULICS
RPESYAN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RPESYAN (RPESYAN) is a pilot-operated, balanced-poppet relief cartridge designed to regulate pressure by opening to tank port 2 when the inlet port 1 reaches the set pressure. This valve is renowned for its accuracy, smooth operation, quietness, speed, and low pressure rise versus flow. The internal modulating feature makes it resistant to cavitation-related issues such as noise and manifold erosion. It can handle maximum pressure at port 2 and is suitable for cross-port relief circuits. The valve's performance remains stable despite varying oil temperatures and contamination, thanks in part to a 150-micron stainless steel screen protecting the main stage orifice. This model is ideal for load-holding applications and allows back pressure on tank port 2 to add directly to the valve setting at a 1:1 ratio. Adjustment options with W and Y controls are available with or without special settings; without special settings, adjustments can be made across the full range. The valve features Sun's floating style construction, minimizing internal binding risks due to installation torque or machining variations. The RPESYAN fits into Cavity T-10A with a series capacity of 25 gpm (95 L/min) and operates at a maximum pressure of 5000 psi (350 bar). It has a typical response time of 7 ms with minimal leakage of up to 10 drops/min (0.7 cc/min) at 110 SUS (24 cSt). The adjustment mechanism involves up to five clockwise turns to increase settings, with specific torque requirements for installation and adjustment components. Weighing in at .30 lb (.15 kg), this cartridge comes with a Viton seal kit option for reliable sealing performance.
