SUN HYDRAULICS
RPGETAN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RPGETAN (Material Number: RPGETAN) is a fast-acting, pilot-operated, balanced piston relief cartridge designed to protect hydraulic components from pressure transients. This normally closed, pressure-limiting valve opens quickly when the inlet port pressure reaches the set point, diverting flow to the tank port to control pressure rise. It features a low-pressure rise versus flow and rapid response time of approximately 2 milliseconds. The cartridge is interchangeable with other 2-port relief cartridges of the same frame size and flow path, allowing for versatile application in hydraulic systems. It can handle maximum pressure at port 2 and is suitable for cross-port relief circuits, although spool leakage should be considered in such applications. The main stage orifice is safeguarded by a 150-micron stainless steel screen, but it is not recommended for load-holding applications due to potential leakage. The RPGETAN can accommodate back pressure on the tank port directly additive to the valve setting at a 1:1 ratio and features EPDM seals compatible with phosphate ester fluids. However, exposure to petroleum-based fluids could damage these seals. The valve incorporates Sun's floating style construction to minimize internal part binding due to installation torque or machining variations. With a capacity of 50 gpm (200 L/min) and a maximum operating pressure of 5000 psi (350 bar), this valve offers robust performance in demanding environments. It requires an installation torque of 45-50 lbf ft (61-68 Nm) and features an adjustment screw with an internal hex size of 5/32 inch (4 mm). The locknut hex size is 9/16 inch (15 mm), with a locknut torque requirement of 80-90 lbf in (9-10 Nm). The model weighs approximately .50 lb (.25 kg) and comes with a Viton seal kit option available under part number 990203006.
