SUN HYDRAULICS
RPIEMEN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RPIEMEN (RPIEMEN) is a fast-acting, pilot-operated, balanced piston relief cartridge designed to protect hydraulic components from pressure transients. This normally closed, pressure-limiting valve opens quickly to manage pressure spikes by throttling flow from the inlet port 1 to the tank port 2 when the set pressure is reached. It features a low-pressure rise versus flow and operates with remarkable speed, making it suitable for applications where rapid response is critical. The valve's design allows for interchangeability with other 2-port relief cartridges of the same frame size, facilitating easy integration into existing systems. It can handle maximum pressure at port 2 and is appropriate for use in cross-port relief circuits, though spool leakage should be considered in such applications. The main stage orifice is safeguarded by a 150-micron stainless steel screen, ensuring durability and reliability. However, this valve is not recommended for load-holding applications due to potential spool leakage. The back pressure on tank port 2 adds directly to the valve setting at a 1:1 ratio. Sun's floating style construction minimizes internal part binding risks caused by excessive installation torque or cavity machining variations. With a cavity size of T-16A and Series 3 capacity of up to 100 gpm (380 L/min), this cartridge can withstand a maximum operating pressure of 5000 psi (350 bar). It has a typical response time of just 2 milliseconds and maintains minimal valve leakage at specified conditions. Adjustments are made via an internal hex screw, with precise control over settings through five clockwise turns. The RPIEMEN model weighs approximately 1.20 lb (0.55 kg) and comes with a Viton seal kit option for enhanced performance in various environments.
