SUN HYDRAULICS
RPKECDN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RPKECDN (RPKECDN) is a fast-acting, pilot-operated, balanced piston relief cartridge designed to protect hydraulic components from pressure transients. This normally closed, pressure-limiting valve opens rapidly to the tank port when the inlet port reaches the preset pressure, effectively throttling flow to limit pressure rise. It features low pressure rise versus flow and provides swift response times, typically around 2 milliseconds. The RPKECDN is capable of handling a maximum operating pressure of 5000 psi (350 bar) and has a capacity of 200 gpm (760 L/min). This relief cartridge is physically and functionally interchangeable with other two-port relief cartridges of the same frame size, making it versatile for various applications. It can accept maximum pressure at port 2 and is suitable for use in cross-port relief circuits; however, users should consider spool leakage in such setups. The main stage orifice is safeguarded by a 150-micron stainless steel screen to prevent contamination. Notably, this valve is not suitable for load-holding applications due to potential spool leakage. The valve's backpressure on the tank port directly adds to the valve setting at a 1:1 ratio. It incorporates Sun's floating style construction, which minimizes internal part binding due to excessive installation torque or machining variations in cavity/cartridge configurations. Installation requires specific torque settings: valve installation torque ranges from 350 to 375 lbf ft (474 to 508 Nm), with an adjustment screw internal hex size of 5/32 inches (4 mm). The model weighs approximately 2.50 lb (1.15 kg) and uses Viton seals for durability and reliability in various environments.
