SUN HYDRAULICS
RPKECQN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RPKECQN (Material Number: RPKECQN) is a fast-acting, pilot-operated, balanced piston relief cartridge designed to protect hydraulic components from pressure transients. This normally closed, pressure-limiting valve operates by opening to tank port 2 when the inlet port 1 reaches the valve setting, thereby throttling flow to limit pressure rise. The design features low pressure rise versus flow and rapid response times, typically around 2 milliseconds. It is capable of handling a maximum operating pressure of 5000 psi (350 bar) and has a capacity of up to 200 gpm (760 L/min). Notably, this relief cartridge is interchangeable with other two-port relief cartridges of the same frame size and flow path. It accepts maximum pressure at port 2 and can be used in cross-port relief circuits with consideration for spool leakage. However, it is not suitable for load-holding applications due to potential leakage. The main stage orifice is safeguarded by a 150-micron stainless steel screen, and back pressure on tank port 2 directly adds to the valve setting at a 1:1 ratio. The RPKECQN incorporates Sun's floating style construction to reduce the risk of internal parts binding from excessive installation torque or machining variations in cavity/cartridge interfaces. The valve requires an installation torque between 350 - 375 lbf ft (474 - 508 Nm) and features an adjustment mechanism that allows for up to five clockwise turns to increase settings. The model weighs approximately 2.50 lb (1.15 kg) and uses Viton seal kits for effective performance across various applications.
