SUN HYDRAULICS
RPKEKBN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RPKEKBN (RPKEKBN) is a fast-acting, pilot-operated, balanced piston relief cartridge designed for protecting hydraulic components from pressure transients. These normally closed, pressure-limiting valves are engineered to open quickly when the inlet port pressure reaches the valve setting, directing flow to tank port 2 to limit further pressure rise. Although they prioritize speed over smoothness in operation, these valves feature a low pressure rise versus flow and are extremely fast in response. They are interchangeable with all 2-port relief cartridges of the same frame size, except for pilot reliefs, and can handle maximum pressure at port 2, making them suitable for cross-port relief circuits. However, when used in such circuits, spool leakage should be considered. The main stage orifice is safeguarded by a 150-micron stainless steel screen. These valves are not recommended for load-holding applications due to potential spool leakage. Additionally, back pressure on tank port 2 directly adds to the valve setting at a 1:1 ratio. The Sun Hydraulics RPKEKBN incorporates floating style construction to reduce the risk of internal parts binding due to excessive installation torque or machining variations. It features a T-18A cavity and Series 4 capacity with a flow rate of up to 200 gpm (760 L/min). The factory pressure settings are established at 4 gpm (15 L/min), with a maximum operating pressure of 5000 psi (350 bar) and typical response time of approximately 2 ms. Maximum valve leakage is rated at 5 in\u00b3/min (80 cc/min) at 110 SUS (24 cSt) and 1000 psi (70 bar). The adjustment involves up to five turns clockwise to increase the setting. This model weighs approximately 2.50 lb (1.15 kg) and uses Viton seal kits for optimal performance under various conditions.
