SUN HYDRAULICS
RQCBCCN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RQCBCCN (RQCBCCN) is a kickdown relief cartridge designed to function similarly to a circuit breaker in an electrical system. This valve is engineered to kick completely open and remain open when the pressure at the inlet port 1 surpasses the valve setting, thereby creating an unrestricted flow path from port 1 to tank port 2. The valve stays open as long as the pressure at port 1 exceeds that at port 2, and it resets only when flow from port 1 to port 2 ceases and the pressure at port 2 equals or exceeds that at port 1. The main stage orifice is safeguarded by a durable 150-micron stainless steel screen, though this product is not suitable for load-holding applications. It is intended for use on the actuator side of systems since flow must cease for resetting; if used on the pump side, pump flow must be halted for reset. Back pressure on tank port 2 directly adds to the valve setting at a one-to-one ratio. All two-port relief cartridges except pilot reliefs are interchangeable in terms of flow path and cavity size for a given frame size. The Sun floating style construction minimizes internal part binding due to excessive installation torque or machining variations. With a capacity of up to 12 gpm (45 L/min) and maximum operating pressure of 5000 psi (350 bar), this cartridge features a response time typically around 25 ms and maximum leakage of approximately 2 in\u00b3/min (30 cc/min) at specified conditions. Adjustments can be made with up to five clockwise turns, with specific torque requirements provided for installation and locknut adjustments.
