SUN HYDRAULICS
RQCBCCV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RQCBCCV (Material Number: RQCBCCV) is a kickdown relief cartridge designed to function similarly to a circuit breaker in hydraulic systems. This valve automatically opens and remains open when the inlet port 1 pressure exceeds the set threshold, allowing unrestricted flow from port 1 to tank port 2. The valve stays open as long as the pressure at port 1 is greater than that at port 2, and it resets only when flow ceases and pressures equalize between the two ports. This model features a main stage orifice protected by a 150-micron stainless steel screen, ensuring durability and performance reliability. It is important to note that this valve is not suitable for load-holding applications and should be installed on the actuator side of the system. If used on the pump side, pump flow must be halted for resetting. The back pressure on tank port 2 directly adds to the valve setting at a 1:1 ratio. All two-port relief cartridges, except pilot reliefs, are interchangeable based on frame size due to their consistent flow path and cavity design. The RQCBCCV incorporates Sun's floating style construction, reducing internal parts binding risk due to installation torque or machining variations. With a capacity of 12 gpm (45 L/min) and maximum operating pressure of 5000 psi (350 bar), this valve offers rapid response times typically around 25 ms with minimal leakage at specified conditions. It includes adjustment features with specific torque requirements for installation and locknut settings. Ideal applications include scenarios like portable grain augers where safety mechanisms are critical for operational security.
