SUN HYDRAULICS
RQCBKBV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RQCBKBV (Material Number: RQCBKBV) is a kickdown relief cartridge designed to function similarly to a circuit breaker in hydraulic systems. This valve is engineered to open completely and maintain an open state once the pressure at the inlet port 1 surpasses the valve's set threshold, thereby establishing an unrestricted flow path from port 1 to tank port 2. The valve remains open as long as the pressure at port 1 exceeds that at port 2. To reset, flow from port 1 to port 2 must stop, and the pressure at port 2 should be equal to or greater than that at port 1. The main stage orifice of this cartridge is safeguarded by a 150-micron stainless steel screen, ensuring durability and performance. This relief cartridge is not intended for load-holding applications and should be used on the actuator side of a system since flow through the valve must cease for reset. If used on the pump side, pump flow must be halted for resetting. Notably, back pressure on tank port 2 directly adds to the valve setting in a 1:1 ratio. It features Sun's floating style construction which minimizes internal part binding due to installation torque or machining variations. The RQCBKBV model has a cavity T-162A series with a capacity of up to 12 gpm (45 L/min) and can operate at pressures up to 5000 psi (350 bar). It typically responds within 25 ms with minimal leakage under specific conditions. Installation requires specific torque settings for optimal performance, and adjustments can be made via an internal hex screw. This model weighs approximately .20 lb (.10 kg) and includes Viton seal kits for enhanced sealing capabilities.
