SUN HYDRAULICS
RQCBKCV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RQCBKCV (Material Number: RQCBKCV) is a kickdown relief cartridge that functions similarly to a circuit breaker in an electrical system. When the pressure at inlet port 1 exceeds the valve setting, the valve kicks completely open, creating an unrestricted flow path from port 1 to tank port 2. It remains open as long as the pressure at port 1 is greater than at port 2. To reset, flow from port 1 to port 2 must stop, and pressure at port 2 must equal or exceed that at port 1. Notably, this valve is not suitable for load-holding applications and should be used on the actuator side of systems where flow through the valve can cease for resetting purposes. If applied on the pump side, pump flow must be halted for reset. The main stage orifice is protected by a 150-micron stainless steel screen, and back pressure on tank port 2 directly adds to the valve setting in a 1:1 ratio. All two-port relief cartridges are interchangeable within their frame size due to consistent flow paths and cavities. This model features Sun's floating style construction to reduce internal part binding from installation torque or machining variations. It has a capacity of up to 12 gpm (45 L/min) and operates up to a maximum pressure of 5000 psi (350 bar). The response time is typically around 25 ms with maximum leakage at specified conditions being minimal. Adjustment details include clockwise turns for setting increase, with specific hex sizes provided for both adjustment screw and locknut installation. The model weighs approximately .20 lb (.10 kg), with available Viton seal kits for maintenance needs.
