SUN HYDRAULICS
RQCBKNV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RQCBKNV (RQCBKNV) is a kickdown relief cartridge designed to function similarly to a circuit breaker in hydraulic systems. This valve automatically opens and remains open when the pressure at the inlet port 1 exceeds the set threshold, allowing unrestricted flow to tank port 2. It stays open as long as the inlet pressure surpasses that of the tank port. Resetting requires cessation of flow from port 1 to port 2, with equal or greater pressure at port 2 compared to port 1. The main stage orifice is safeguarded by a 150-micron stainless steel screen, ensuring durability and reliability. Notably, this valve is unsuitable for load-holding applications and is intended for actuator-side use, as flow must cease for resetting; if used on the pump side, pump flow must be halted for reset. Back pressure on tank port 2 directly adds to the valve setting at a 1:1 ratio. The RQCBKNV features Sun's floating style construction to reduce internal part binding due to excessive torque or machining variations during installation. It fits into cavity T-162A, Series 0, with a capacity of up to 12 gpm (45 L/min) and can handle a maximum operating pressure of 5000 psi (350 bar). The typical response time is approximately 25 ms, with minimal leakage at specified conditions. Adjustments are made via an internal hex screw, with specific torque settings provided for installation and locknut adjustments. The cartridge weighs .20 lb (.10 kg) and uses a Viton seal kit (990-162-006). An example application includes use in portable grain augers where it provides safety by tripping under excess pressure conditions.
