SUN HYDRAULICS
RQCBLAN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RQCBLAN (Material Number: RQCBLAN) is a kickdown relief cartridge designed to function similarly to a circuit breaker within hydraulic systems. This valve opens completely and stays open when the inlet port 1 pressure surpasses the set threshold, allowing unrestricted flow from port 1 to tank port 2. It remains open as long as the pressure at port 1 is greater than at port 2. To reset, flow through the valve must stop, and the pressure at port 2 must equal or exceed that of port 1. The main stage orifice features a protective 150-micron stainless steel screen. The RQCBLAN model is not suitable for load-holding applications and is intended for use on the actuator side of hydraulic systems, requiring flow cessation for reset; if used on the pump side, pump flow must be halted for reset. Back pressure on tank port 2 directly adds to the valve setting at a 1:1 ratio. The cartridge utilizes Sun's floating style construction to minimize internal binding risks due to excessive installation torque or machining variations. It fits into cavity T-162A and offers a capacity of up to 12 gpm (45 L/min) with a maximum operating pressure of 5000 psi (350 bar). The typical response time is approximately 25 ms, with maximum valve leakage rated at two in\u00b3/min (30 cc/min) at specific conditions. Adjustments are made via an internal hex screw, with five clockwise turns increasing settings; installation torque ranges from 20-25 lbf ft (27-33 Nm). This model weighs .20 lb (.10 kg), and an optional Viton seal kit (990162006) can be utilized for enhanced sealing performance in various applications such as safety mechanisms in agricultural equipment like grain augers.
